SS0912 Fully Configurable A/D Interface for ECU Board (dual-fuel engine)

SHORT DESCRIPTION

SS0912 is a fully-programmable interface for sensors and actuators specifically designed for ECU in dual-fuel vehicles.

Technical documents under

confidentiality agreement

KEY FEATURES

• 4MHz SPI interface
• One-Time Programmable 32 bit memory
• 2 Digital-to-Analog conversion channels
  • 9 bit resolution
  • 1kHz conversion rate
  • Voltage/Current mode output
• 2 single-ended rail-to-rail analog inputs
• 3 rail-to-rail I/O, gain-programmable INA
• 8 Digital input channels with programmable threshold and hysteresis
• 2 Open-Drain digital outputs
• 1 Differential-Input to CMOS output channel
• High-Voltage input robustness
• 4-kV HBM ESD protection
• Automotive temperature range (-40÷125°C)
• 5V Supply voltage

MAINSTREAM APPLICATIONS

• Dual-Fuel engines ECU interface

PACKAGE OPTIONS

• 56 leads TSSOP
• RoSH compliance
• Halogen-Free compliance
